Welding and Soldering Automation Case Studies

Automated assembly line concept for automotive drive-motor temperature sensors, covering wire cutting, NTC welding, coating, curing, crimping and testing.

Automated Production Line for automotive NTC water-temperature sensors, linking NTC DC welding, tray transfer, glue dispensing, curing, riveting, laser marking and testing.

Automated Welding concept for electronics wire carrier boards, combining payoff, cutting, stripping, tape bonding, component forming and resistance welding without tinning.

Automated assembly solutions line for single-end wire products, integrating wire cutting, board loading, welding, CCD checks, tube pushing, forming and collection.

Bushing Automatic Assembly Line for AC/DC socket components, combining thermistor forming, housing feeding, resistor assembly, laser welding, testing and tray loading.

Automotive NTC assembly line project for single-end sensors, covering boarding, welding, encapsulation, shell potting, 25 C and 85 C testing and data collection.

Automated Cleaning Line for electronics resistors with magnetically retained leads, combining rust remover, pure-water rinses, alcohol cleaning and basket transfer.

Automated Production line for 58-ohm NTC sensors, combining wire cutting, boarding, dual-station soldering, encapsulation, curing fixtures and testing.

Automated Soldering Equipment for wire-core square pressing, resistor co-welding and secondary flat welding in a compact 1,400 x 800 x 1,900 mm cell.

Automated assembly system and Automated Test System for NTC finishing, adding CCD weld-offset inspection and automatic cleaning to boarding, soldering and testing.
