Case Studies in Custom Automation for Manufacturing

Automated CCD vision inspection and tray loading system for small components, combining indexed transfer, controlled illumination and organized tray output.

Material Handling concept for ten test machines, using stacked tray transfer, line-side roller docking and a composite robot to keep automated testing supplied.

Automotive oil temperature sensor CCD vision inspection machine with multi-position fixtures, automated transfer, controlled lighting and multi-view image analysis.

Automotive oil temperature sensor resistance testing machine with fixture transfer, 0°C and 25°C water baths, automatic electrical contact and multi-position measurement.

Intralogistics transformation for six coating lines, handling heavy roll material with AGV transport, roll storage constraints and dispatch-system visibility.

AGV robot transfer cell combining a composite robot, receiving AGV, roller docking table and electric gripper tooling for tray-based machine-side material flow.

CR-4000C inline automatic screw fastening system for large electronic module assembly, using gantry motion and dual screwdriving heads for multi-point fastening.

Automated assembly line concept for automotive drive-motor temperature sensors, covering wire cutting, NTC welding, coating, curing, crimping and testing.

AGV material handling cell for tray feeding, roller docking and machine-side transfer, built around a compact composite mechanical AGV layout.

Automated Optical Inspection cell for finished sensors, using multi-direction CCD checks, transfer receiving, NG marking and manual unloading at 1,500 to 1,800 pcs/hour.
